BOLT ENERGY USA THE BEST BATTERY ON THE PLANET!
Brent Tenney and Bobby Diaz, both engineers and fellow golf car dealership owners, founded Bolt Energy USA out of their frustration with the low-quality lithium-ion golf car batteries available on the market. They set out to create the best lithium-ion battery on the planet keeping the desires and needs of the consumer at the forefront! Bolt Energy USA now designs, produces, and assembles lithium-ion batteries for retail and commercial applications. Their motto is “Do it right the first time” since they were tired of replacing subpar components that other manufactures used with their products.
BOLT BATTERIES ARE COMPATIBLE WITH ALL MAJOR GOLF CART MANUFACTURES.
BOLT ENERGY USA IS THE LEADING GOLF CART LITHIUM BATTERY COMPANY IN THE USA
What sets Bolt Lithium batteries apart from the competition?
- BMS (Battery Management System) DATA/specifications that perform to listed specs and more.
- Most complete and thorough battery kits
- Industry leading10-year warranty.
- Best selection of Amp Hours, battery sizes and selection of products
- Bluetooth app that can diagnose your vehicle before a tech arrives.
- Easy to follow instructions. Owners, manuals written in English.
- Build quality like none other. Everything from the extension cord, to the charger, to the parts, accessories and battery are made to work in unison, essentially eliminating any weak points in the chain.
BOLT BELIEVES IN IT’S PRODUCT, YOU SHOULD TOO.
10-year warranty, the best in the business
5-Year repair or replace
Followed by 5-year prorated
Accessories come with 1-year warranty
Transparent – fully detailed in the owners-manual
Dealer or customer can register online
105AH 38 Volt Standard Kit BE10538M “MINI” P/N: BE10538M Stan-K
Standard Kit includes the following:
- 38V-105AH BATTERY
- Bluetooth receiver
- SOC “state of charge meter”
- Owners manual “SIMPLE installation instructions”
- 6- 3/8 battery ring terminal connectors
- 10-10″ tie straps
- Bolt Energy USA sticker/s
- Waterproof high speed charger
- Mounting brackets, Nutts & bolts
MECHANICAL SPECIFICATIONS
- Dimensions (L x W x H): 11.14″ x 10.58″ x 10.67″
- Weight: 77.27lbs (35.05kg)
- Terminal Type: M8*1.5*25mm
- Cell Configuration: 1P16S
- Case Material: Powder Coated Steel
- Enclosure Protection: Designed with IP66 Stardard
- Cell Type – Chemistry: Prismatic- LiFePO4
DISCHARGE SPECIFICATIONS
- Maximum Continuous Discharge Current: 250A
- Peak Discharge Current: 520A ± 15.6A (30S)
-
BMS Discharge Current Cut-Off:
260 A ± A7.8A (50S)
520A ± 15.6A (30S) - BMS Discharge Voltage Cut-Off: 30V
- Recommended Low Voltage Disconnect: 36.0V
- BMS Reconnect Voltage: 31.2V
- Discharge Temperature: -4 to 149°F (-20 to 65°C)
ELECTRICAL SPECIFICATION
- Nominal Voltage: 38.4V
- Working Voltage: 32.4 – 43.8V
- Recommended Voltage: 36.0V – 42.6V
- Nominal Capacity: 105Ah
- Energy: 4.032KWh
- Capacity @ 25A: 252 min
- Efficiency: 0.99
- Self Discharge: <3% per Month
CHARGE SPECIFICATIONS
- Recommended Charge Current: 5 – 52A
- Maximum Input Current: 350A
- Charge Current Cut-Off: 375A
- BMS Charge Voltage Cut-Off: 43.8V
- Reconnect Voltage: <43.8V
- Charging Temp. Range: 34°F to 140°F (0-60°C)
COMMUNICATION
- Bluetooth: Bluetooth receiver
- CAN: CAN port for testing battery
105AH 38 Volt Professional Kit BE10538M “MINI” P/N BE10538M Pro-K
- 38V-105AH BATTERY
- Bluetooth receiver
- SOC “state of charge meter”
- Owners manual “SIMPLE installation instructions”
- 6- 3/8 battery ring terminal connectors
- 10-10″ tie straps
- Bolt Energy USA sticker/s
- Waterproof high speed charger
- Mounting brackets, Nutts & bolts
- AC Hardwire PORT
- DECO Cover plate AC hardwire universal or club car
- 30 amp reducer
- 2-40″ 2AWG premium installation cables
- 48V- 400A solenoid
- Lead battery removal strap
MECHANICAL SPECIFICATIONS
- Dimensions (L x W x H): 11.14″ x 10.58″ x 10.67″
- Weight: 77.27lbs (35.05kg)
- Terminal Type: M8*1.5*25mm
- Cell Configuration: 1P16S
- Case Material: Powder Coated Steel
- Enclosure Protection: Designed with IP66 Stardard
- Cell Type – Chemistry: Prismatic- LiFePO4
DISCHARGE SPECIFICATIONS
- Maximum Continuous Discharge Current: 250A
- Peak Discharge Current: 520A ± 15.6A (30S
-
BMS Discharge Current Cut-Off:
260 A ± A7.8A (50S)
520A ± 15.6A (30S) - BMS Discharge Voltage Cut-Off: 30V
- Recommended Low Voltage Disconnect: 36.0V
- BMS Reconnect Voltage: 31.2V
- Discharge Temperature: -4 to 149°F (-20 to 65°C)
ELECTRICAL SPECIFICATION
- Nominal Voltage: 38.4V
- Working Voltage: 32.4 – 43.8V
- Recommended Voltage: 36.0V – 42.6V
- Nominal Capacity: 105Ah
- Energy: 4.032KWh
- Capacity @ 25A: 252 min
- Efficiency: 0.99
- Self Discharge: <3% per Month
CHARGE SPECIFICATIONS
- Recommended Charge Current: 5 – 52A
- Maximum Input Current: 350A
- Charge Current Cut-Off: 375A
- BMS Charge Voltage Cut-Off: 43.8V
- Reconnect Voltage: <43.8V
- Charging Temp. Range: 34°F to 140°F (0-60°C)
COMMUNICATION
- Bluetooth: Bluetooth receiver
- CAN: CAN port for testing battery
105AH 51 Volt Standard Kit BE10551M “MINI” P/N BE10551M Stan-K
- 51V-105AH BATTERY
- Bluetooth receiver
- SOC “state of charge meter”
- Owners manual “SIMPLE installation instructions”
- 6- 3/8 battery ring terminal connectors
- 10-10″ tie straps
- Bolt Energy USA sticker/s
- Waterproof high speed charger
- Mounting brackets, Nutts & bolts
MECHANICAL SPECIFICATIONS
- Dimensions (L x W x H): 12.8″ x 12.01″ x 10.42″
- Weight: 100.8lbs (45.7kg)
- Terminal Type: M8*1.5*25mm
- Cell Configuration: 1P16S
- Case Material: Powder Coated Steel
- Enclosure Protection: Designed with IP66 Stardard
- Cell Type – Chemistry: Prismatic- LiFePO4
DISCHARGE SPECIFICATIONS
- Maximum Continuous Discharge Current: 250A
- Peak Discharge Current: 520A ± 15.6A (30S)
-
BMS Discharge Current Cut-Off:
260 A ± A7.8A (50S)
520A ± 15.6A (30S) - BMS Discharge Voltage Cut-Off: 40V
- Recommended Low Voltage Disconnect: 48.0V
- BMS Reconnect Voltage: 41.6V
- Discharge Temperature: -4 to 149°F (-20 to 65°C)
ELECTRICAL SPECIFICATION
- Nominal Voltage: 51.2V
- Working Voltage: 43.2 – 58.4V
- Recommended Voltage: 48.0V – 57.0V
- Nominal Capacity: 105Ah
- Energy: 5,376Wh
- Capacity @ 25A: 252 min
- Efficiency: 0.99
- Self Discharge: <3% per Month
CHARGE SPECIFICATIONS
- Recommended Charge Current: 5 – 52A
- Maximum Input Current: 350A
- Charge Current Cut-Off: 375A
- BMS Charge Voltage Cut-Off: 58.5V
- Reconnect Voltage: <58.5V
- Charging Temp. Range: 34°F to 140°F (0-60°C)
COMMUNICATION
- Bluetooth: Bluetooth receiver
- CAN: CAN port for testing battery
105AH 51 Volt Professional Kit BE10551M “MINI” P/N BE10551M Pro-K
- 51V-105AH BATTERY
- Bluetooth receiver
- SOC “state of charge meter”
- Owners manual “SIMPLE installation instructions”
- 6- 3/8 battery ring terminal connectors
- 10-10″ tie straps
- Bolt Energy USA sticker/s
- Waterproof high speed charger
- Mounting brackets, Nutts & bolts
- AC Hardwire PORT
- DECO Cover plate AC hardwire universal or club car
- 30 amp reducer
- 2-40″ 2AWG premium installation cables
- 48V- 400A solenoid
- Lead battery removal strap
MECHANICAL SPECIFICATIONS
- Dimensions (L x W x H): 12.8″ x 12.01″ x 10.42″
- Weight: 100.8lbs (45.7kg)
- Terminal Type: M8*1.5*25mm
- Cell Configuration: 1P16S
- Case Material: Powder Coated Steel
- Enclosure Protection: Designed with IP66 Stardard
- Cell Type – Chemistry: Prismatic- LiFePO4
DISCHARGE SPECIFICATIONS
- Maximum Continuous Discharge Current: 250A
- Peak Discharge Current: 520A ± 15.6A (30S
-
BMS Discharge Current Cut-Off:
260 A ± A7.8A (50S)
520A ± 15.6A (30S) - BMS Discharge Voltage Cut-Off: 40V
- Recommended Low Voltage Disconnect: 48.0V
- BMS Reconnect Voltage: 41.6V
- Discharge Temperature: -4 to 149°F (-20 to 65°C)
ELECTRICAL SPECIFICATION
- Nominal Voltage: 38.4V
- Working Voltage: 32.4 – 43.8V
- Recommended Voltage: 36.0V – 42.6V
- Nominal Capacity: 105Ah
- Energy: 5,376Wh
- Capacity @ 25A: 252 min
- Efficiency: 0.99
- Self Discharge: <3% per Month
CHARGE SPECIFICATIONS
- Recommended Charge Current: 5 – 52A
- Maximum Input Current: 350A
- Charge Current Cut-Off: 375A
- BMS Charge Voltage Cut-Off: 58.5V
- Reconnect Voltage: <58.5V
- Charging Temp. Range: 34°F to 140°F (0-60°C)
COMMUNICATION
- Bluetooth: Bluetooth receiver
- CAN: CAN port for testing battery
105AH 51 Volt Professional Kit “THIN” P/N BE10551T Pro-K
- 51V-105AH BATTERY
- Bluetooth receiver
- SOC “state of charge meter”
- Owners manual “SIMPLE installation instructions”
- 6- 3/8 battery ring terminal connectors
- 10-10″ tie straps
- Bolt Energy USA sticker/s
- Waterproof high speed charger
- Mounting brackets, Nutts & bolts
- AC Hardwire PORT
- DECO Cover plate AC hardwire universal or club car
- 30 amp reducer
- 2-40″ 2AWG premium installation cables
- 48V- 400A solenoid
- Lead battery removal strap
MECHANICAL SPECIFICATIONS
- Dimensions (L x W x H): 20″ x 8.43″ x 10.65″
- Weight: 105lbs (47.63kg)
- Terminal Type: M8*1.5*25mm
- Cell Configuration: 1P16S
- Case Material: Powder Coated Steel
- Enclosure Protection: Designed with IP66 Stardard
- Cell Type – Chemistry: Prismatic- LiFePO4
DISCHARGE SPECIFICATIONS
- Maximum Continuous Discharge Current: 250A
- Peak Discharge Current: 520A ± 15.6A (30S)
-
BMS Discharge Current Cut-Off:
260 A ± A7.8A (50S)
520A ± 15.6A (30S) - BMS Discharge Voltage Cut-Off: 40V
- Recommended Low Voltage Disconnect: 48.0V
- BMS Reconnect Voltage: 41.6V
- Discharge Temperature: -4 to 149°F (-20 to 65°C)
ELECTRICAL SPECIFICATION
- Nominal Voltage: 51.2V
- Working Voltage: 43.2 – 58.4V
- Recommended Voltage: 48.0V – 57.0V
- Nominal Capacity: 105Ah
- Energy: 5,376Wh
- Capacity @ 25A: 252 min
- Efficiency: 0.99
- Self Discharge: <3% per Month
CHARGE SPECIFICATIONS
- Recommended Charge Current: 5 – 52A
- Maximum Input Current: 350A
- Charge Current Cut-Off: 375A
- BMS Charge Voltage Cut-Off: 58.5V
- Reconnect Voltage: <58.5V
- Charging Temp. Range: 34°F to 140°F (0-60°C)
COMMUNICATION
- Bluetooth: Bluetooth receiver
- CAN: CAN port for testing battery
105AH 72 Volt Professional Kit “POWER” P/N BE10572P Pro-K
- 72V-105AH BATTER
- Bluetooth receiver
- SOC “state of charge meter”
- Owners manual “SIMPLE installation instructions”
- 6- 3/8 battery ring terminal connectors
- 10-10″ tie straps
- Bolt Energy USA sticker/s
- Waterproof high speed charger
- Mounting brackets, Nutts & bolts
- AC Hardwire PORT
- DECO Cover plate AC hardwire universal or club car
- 50 amp reducer
- 2-40″ 2AWG premium installation cables
- 72V- 400A solenoid
- Lead battery removal strap
MECHANICAL SPECIFICATIONS
- Dimensions (L x W x H): 20.08″ x 10.75″ x 10.39″
- Weight: 137.26lbs (62.26kg)
- Terminal Type: M8*1.5*25mm
- Cell Configuration: 1P23S
- Case Material: Powder Coated Steel
- Enclosure Protection: Designed with IP66 Stardard
- Cell Type – Chemistry: Prismatic- LiFePO4
DISCHARGE SPECIFICATIONS
- Maximum Continuous Discharge Current: 250A
- Peak Discharge Current: 520A ± 15.6A (30S
-
BMS Discharge Current Cut-Off:
260 A ± A7.8A (50S)
520A ± 15.6A (30S) - BMS Discharge Voltage Cut-Off: 57.5V
- Recommended Low Voltage Disconnect: 69.0V
- BMS Reconnect Voltage: 60.0V
- Discharge Temperature: -4 to 149°F (-20 to 65°C)
ELECTRICAL SPECIFICATION
- Nominal Voltage: 73.6V
- Working Voltage: 62 – 83.95V
- Recommended Voltage: 69V – 81.93V
- Nominal Capacity: 105Ah
- Energy: 7,728Wh
- Capacity @ 25A: 420 min
- Efficiency: 0.99
- Self Discharge: <3% per Month
CHARGE SPECIFICATIONS
- Recommended Charge Current: 5 – 52A
- Maximum Input Current: 350A
- Charge Current Cut-Off: 375A
- BMS Charge Voltage Cut-Off: 84V
- Reconnect Voltage: <84V
- Charging Temp. Range: 34°F to 140°F (0-60°C)
COMMUNICATION
- Bluetooth: Bluetooth receiver
- CAN: CAN port for testing battery
