BOLT ENERGY USA THE BEST BATTERY ON THE PLANET!
Brent Tenney and Bobby Diaz, both engineers and fellow golf car dealership owners, founded Bolt Energy USA out of their frustration with the low-quality lithium-ion golf car batteries available on the market. They set out to create the best lithium-ion battery on the planet keeping the desires and needs of the consumer at the forefront! Bolt Energy USA now designs, produces, and assembles lithium-ion batteries for retail and commercial applications. Their motto is “Do it right the first time” since they were tired of replacing subpar components that other manufactures used with their products.
BOLT BATTERIES ARE COMPATIBLE WITH ALL MAJOR GOLF CART MANUFACTURERS.
BOLT ENERGY USA IS THE LEADING GOLF CART LITHIUM BATTERY COMPANY IN THE USA
What sets Bolt Lithium batteries apart from the competition?
- BMS (Battery Management System) data/specifications that perform to listed specs and more.
- Most complete and thorough battery kits – every Standard Kit includes the battery, Bluetooth receiver, Smart SOC meter, waterproof high-speed charger, AC hardwire port, DECO cover plate, 15 ft lighted extension cord and mounting hardware.
- Industry-leading 12-year transferable warranty.
- Best selection of amp hours and battery sizes – 38V, 51V and 72V packs from 60Ah to 160Ah, with up to 70 miles of range.
- Heated and non-heated versions available on every model.
- Bluetooth app that can diagnose your vehicle before a tech arrives.
- Easy to follow instructions. Owner’s manuals written in English.
- Build quality like none other. Everything from the extension cord, to the charger, to the parts, accessories and battery are made to work in unison, essentially eliminating any weak points in the chain.
BOLT BELIEVES IN ITS PRODUCT, YOU SHOULD TOO.
12-year transferable warranty – the best in the business
Years 1–6: full repair or replacement coverage
Years 7–12: prorated coverage
Charger covered 2 years, accessories 1 year
Transferable to the next owner of your cart
Register online within 30 days for the full 12 years
12-year transferable warranty – the best in the business
105AH 38 Volt Standard Kit BE10538M “MINI” P/N: BE10538M Stan-K
Standard Kit includes the following:
- 38.4V-105AH battery
- Bluetooth receiver
- Smart SOC “state of charge” meter
- Owner’s manual with simple installation instructions
- 6 – 3/8″ battery ring terminal connectors
- 10 – 10″ tie straps
- Waterproof high-speed charger
- Mounting bracket, nuts & bolts
- AC hardwire port
- DECO cover plate (universal or Club Car)
- 15 ft 12-AWG lighted extension cord
- Bolt Energy USA stickers
- 12-year transferable warranty
MECHANICAL SPECIFICATIONS
- Dimensions (L x W x H): 11.14″ x 10.58″ x 10.67″
- Weight: 77.27lbs (35.05kg)
- Terminal Type: M8*1.5*25mm
- Cell Configuration: 1P16S
- Case Material: Powder Coated Steel
- Enclosure Protection: Designed with IP66 Standard
- Cell Type – Chemistry: Prismatic- LiFePO4
DISCHARGE SPECIFICATIONS
- Maximum Continuous Discharge Current: 250A
- Peak Discharge Current: 520A ± 15.6A (30S)
-
BMS Discharge Current Cut-Off:
260 A ± A7.8A (50S)
520A ± 15.6A (30S) - BMS Discharge Voltage Cut-Off: 30V
- Recommended Low Voltage Disconnect: 36.0V
- BMS Reconnect Voltage: 31.2V
- Discharge Temperature: -4 to 149°F (-20 to 65°C)
ELECTRICAL SPECIFICATION
- Nominal Voltage: 38.4V
- Working Voltage: 32.4 – 43.8V
- Recommended Voltage: 36.0V – 42.6V
- Nominal Capacity: 105Ah
- Energy: 4.032KWh
- Capacity @ 25A: 252 min
- Efficiency: 0.99
- Self Discharge: <3% per Month
CHARGE SPECIFICATIONS
- Recommended Charge Current: 5 – 52A
- Maximum Input Current: 350A
- Charge Current Cut-Off: 375A
- BMS Charge Voltage Cut-Off: 43.8V
- Reconnect Voltage: <43.8V
- Charging Temp. Range: 34°F to 140°F (0-60°C)
COMMUNICATION
- Bluetooth: Bluetooth receiver
- CAN: CAN port for testing battery
105AH 51 Volt Standard Kit BE10551M “MINI” P/N BE10551M Stan-K
Standard Kit includes the following:
- 51.2V-105AH battery
- Bluetooth receiver
- Smart SOC “state of charge” meter
- Owner’s manual with simple installation instructions
- 6 – 3/8″ battery ring terminal connectors
- 10 – 10″ tie straps
- Waterproof high-speed charger
- Mounting bracket, nuts & bolts
- AC hardwire port
- DECO cover plate (universal or Club Car)
- 15 ft 12-AWG lighted extension cord
- Bolt Energy USA stickers
- 12-year transferable warranty
MECHANICAL SPECIFICATIONS
- Dimensions (L x W x H): 12.8″ x 12.01″ x 10.42″
- Weight: 100.8lbs (45.7kg)
- Terminal Type: M8*1.5*25mm
- Cell Configuration: 1P16S
- Case Material: Powder Coated Steel
- Enclosure Protection: Designed with IP66 Standard
- Cell Type – Chemistry: Prismatic- LiFePO4
DISCHARGE SPECIFICATIONS
- Maximum Continuous Discharge Current: 250A
- Peak Discharge Current: 520A ± 15.6A (30S)
-
BMS Discharge Current Cut-Off:
260 A ± A7.8A (50S)
520A ± 15.6A (30S) - BMS Discharge Voltage Cut-Off: 40V
- Recommended Low Voltage Disconnect: 48.0V
- BMS Reconnect Voltage: 41.6V
- Discharge Temperature: -4 to 149°F (-20 to 65°C)
ELECTRICAL SPECIFICATION
- Nominal Voltage: 51.2V
- Working Voltage: 43.2 – 58.4V
- Recommended Voltage: 48.0V – 57.0V
- Nominal Capacity: 105Ah
- Energy: 5,376Wh
- Capacity @ 25A: 252 min
- Efficiency: 0.99
- Self Discharge: <3% per Month
CHARGE SPECIFICATIONS
- Recommended Charge Current: 5 – 52A
- Maximum Input Current: 350A
- Charge Current Cut-Off: 375A
- BMS Charge Voltage Cut-Off: 58.5V
- Reconnect Voltage: <58.5V
- Charging Temp. Range: 34°F to 140°F (0-60°C)
COMMUNICATION
- Bluetooth: Bluetooth receiver
- CAN: CAN port for testing battery
60AH 51 Volt Standard Kit BE6051M “FLEET” P/N BE6051M Stan-K
Standard Kit includes the following:
- 51.2V-60AH battery
- Bluetooth receiver
- Smart SOC “state of charge” meter
- Owner’s manual with simple installation instructions
- 6 – 3/8″ battery ring terminal connectors
- 10 – 10″ tie straps
- Waterproof high-speed charger
- Mounting bracket, nuts & bolts
- AC hardwire port
- DECO cover plate (universal or Club Car)
- 15 ft 12-AWG lighted extension cord
- Bolt Energy USA stickers
- 12-year transferable warranty
MECHANICAL SPECIFICATIONS
- Dimensions (L x W x H): 12.8″ x 12.01″ x 10.28″
- Weight: 72.75lbs (33kg)
- Terminal Type: M8*1.5*25mm
- Cell Configuration: 1P16S
- Case Material: Powder Coated Steel
- Enclosure Protection: Designed with IP66 Standard
- Cell Type – Chemistry: Prismatic- LiFePO4
DISCHARGE SPECIFICATIONS
- Maximum Continuous Discharge Current: 250A
- Peak Discharge Current: 520A ± 15.6A (30S)
-
BMS Discharge Current Cut-Off:
260 A ± A7.8A (50S)
520A ± 15.6A (30S) - BMS Discharge Voltage Cut-Off: 40V
- Recommended Low Voltage Disconnect: 48.0V
- BMS Reconnect Voltage: 41.6V
- Discharge Temperature: -4 to 149°F (-20 to 65°C)
ELECTRICAL SPECIFICATION
- Nominal Voltage: 51.2V
- Working Voltage: 43.2 – 58.4V
- Recommended Voltage: 48.0V – 57.0V
- Nominal Capacity: 60Ah
- Energy: 3,072Wh
- Capacity @ 25A: 144 min
- Efficiency: 0.99
- Self Discharge: <3% per Month
CHARGE SPECIFICATIONS
- Recommended Charge Current: 5 – 52A
- Maximum Input Current: 350A
- Charge Current Cut-Off: 375A
- BMS Charge Voltage Cut-Off: 58.5V
- Reconnect Voltage: <58.5V
- Charging Temp. Range: 34°F to 140°F (0-60°C)
COMMUNICATION
- Bluetooth: Bluetooth receiver
- CAN: CAN port for testing battery
160AH 51 Volt Standard Kit “LONG RANGE” – up to 70 miles
Standard Kit includes the following:
- 51.2V-160AH battery
- Bluetooth receiver
- Smart SOC “state of charge” meter
- Owner’s manual with simple installation instructions
- 6 – 3/8″ battery ring terminal connectors
- 10 – 10″ tie straps
- Waterproof high-speed charger
- Mounting bracket, nuts & bolts
- AC hardwire port
- DECO cover plate (universal or Club Car)
- 15 ft 12-AWG lighted extension cord
- Bolt Energy USA stickers
- 12-year transferable warranty
MECHANICAL SPECIFICATIONS
- Dimensions (L x W x H): 29.57″ x 10.17″ x 9.13″
- Weight: 153lbs (69.4kg)
- Terminal Type: M8*1.5*25mm
- Cell Configuration: 1P16S
- Case Material: Powder Coated Steel
- Enclosure Protection: Designed with IP66 Standard
- Cell Type – Chemistry: Prismatic- LiFePO4
DISCHARGE SPECIFICATIONS
- Maximum Continuous Discharge Current: 250A
- Peak Discharge Current: 520A ± 15.6A (30S)
-
BMS Discharge Current Cut-Off:
260 A ± A7.8A (50S)
520A ± 15.6A (30S) - BMS Discharge Voltage Cut-Off: 40V
- Recommended Low Voltage Disconnect: 48.0V
- BMS Reconnect Voltage: 41.6V
- Discharge Temperature: -4 to 149°F (-20 to 65°C)
ELECTRICAL SPECIFICATION
- Nominal Voltage: 51.2V
- Working Voltage: 43.2 – 58.4V
- Recommended Voltage: 48.0V – 57.0V
- Nominal Capacity: 160Ah
- Energy: 8,192Wh
- Capacity @ 25A: 384 min
- Efficiency: 0.99
- Self Discharge: <3% per Month
CHARGE SPECIFICATIONS
- Recommended Charge Current: 5 – 52A
- Maximum Input Current: 350A
- Charge Current Cut-Off: 375A
- BMS Charge Voltage Cut-Off: 58.5V
- Reconnect Voltage: <58.5V
- Charging Temp. Range: 34°F to 140°F (0-60°C)
COMMUNICATION
- Bluetooth: Bluetooth receiver
- CAN: CAN port for testing battery
105AH 51 Volt Professional Kit BE10551M “MINI” P/N BE10551M Pro-K
Professional Kit includes everything in the Standard Kit plus installation hardware:
- 51.2V-105AH battery
- Bluetooth receiver
- Smart SOC “state of charge” meter
- Owner’s manual with simple installation instructions
- 6 – 3/8″ battery ring terminal connectors
- 10 – 10″ tie straps
- Waterproof high-speed charger
- Mounting bracket, nuts & bolts
- AC hardwire port
- DECO cover plate (universal or Club Car)
- 15 ft 12-AWG lighted extension cord
- Bolt Energy USA stickers
- 12-year transferable warranty
- 30-amp voltage reducer
- 2 – 40″ 2AWG premium installation cables
- 48V 400A heavy-duty solenoid
- Lead battery removal strap
MECHANICAL SPECIFICATIONS
- Dimensions (L x W x H): 12.8″ x 12.01″ x 10.42″
- Weight: 100.8lbs (45.7kg)
- Terminal Type: M8*1.5*25mm
- Cell Configuration: 1P16S
- Case Material: Powder Coated Steel
- Enclosure Protection: Designed with IP66 Standard
- Cell Type – Chemistry: Prismatic- LiFePO4
DISCHARGE SPECIFICATIONS
- Maximum Continuous Discharge Current: 250A
- Peak Discharge Current: 520A ± 15.6A (30S
-
BMS Discharge Current Cut-Off:
260 A ± A7.8A (50S)
520A ± 15.6A (30S) - BMS Discharge Voltage Cut-Off: 40V
- Recommended Low Voltage Disconnect: 48.0V
- BMS Reconnect Voltage: 41.6V
- Discharge Temperature: -4 to 149°F (-20 to 65°C)
ELECTRICAL SPECIFICATION
- Nominal Voltage: 38.4V
- Working Voltage: 32.4 – 43.8V
- Recommended Voltage: 36.0V – 42.6V
- Nominal Capacity: 105Ah
- Energy: 5,376Wh
- Capacity @ 25A: 252 min
- Efficiency: 0.99
- Self Discharge: <3% per Month
CHARGE SPECIFICATIONS
- Recommended Charge Current: 5 – 52A
- Maximum Input Current: 350A
- Charge Current Cut-Off: 375A
- BMS Charge Voltage Cut-Off: 58.5V
- Reconnect Voltage: <58.5V
- Charging Temp. Range: 34°F to 140°F (0-60°C)
COMMUNICATION
- Bluetooth: Bluetooth receiver
- CAN: CAN port for testing battery
105AH 51 Volt Professional Kit “THIN” P/N BE10551T Pro-K
Professional Kit includes everything in the Standard Kit plus installation hardware:
- 51.2V-105AH battery (thin)
- Bluetooth receiver
- Smart SOC “state of charge” meter
- Owner’s manual with simple installation instructions
- 6 – 3/8″ battery ring terminal connectors
- 10 – 10″ tie straps
- Waterproof high-speed charger
- Mounting bracket, nuts & bolts
- AC hardwire port
- DECO cover plate (universal or Club Car)
- 15 ft 12-AWG lighted extension cord
- Bolt Energy USA stickers
- 12-year transferable warranty
- 30-amp voltage reducer
- 2 – 40″ 2AWG premium installation cables
- 48V 400A heavy-duty solenoid
- Lead battery removal strap
MECHANICAL SPECIFICATIONS
- Dimensions (L x W x H): 20″ x 8.43″ x 10.65″
- Weight: 105lbs (47.63kg)
- Terminal Type: M8*1.5*25mm
- Cell Configuration: 1P16S
- Case Material: Powder Coated Steel
- Enclosure Protection: Designed with IP66 Standard
- Cell Type – Chemistry: Prismatic- LiFePO4
DISCHARGE SPECIFICATIONS
- Maximum Continuous Discharge Current: 250A
- Peak Discharge Current: 520A ± 15.6A (30S)
-
BMS Discharge Current Cut-Off:
260 A ± A7.8A (50S)
520A ± 15.6A (30S) - BMS Discharge Voltage Cut-Off: 40V
- Recommended Low Voltage Disconnect: 48.0V
- BMS Reconnect Voltage: 41.6V
- Discharge Temperature: -4 to 149°F (-20 to 65°C)
ELECTRICAL SPECIFICATION
- Nominal Voltage: 51.2V
- Working Voltage: 43.2 – 58.4V
- Recommended Voltage: 48.0V – 57.0V
- Nominal Capacity: 105Ah
- Energy: 5,376Wh
- Capacity @ 25A: 252 min
- Efficiency: 0.99
- Self Discharge: <3% per Month
CHARGE SPECIFICATIONS
- Recommended Charge Current: 5 – 52A
- Maximum Input Current: 350A
- Charge Current Cut-Off: 375A
- BMS Charge Voltage Cut-Off: 58.5V
- Reconnect Voltage: <58.5V
- Charging Temp. Range: 34°F to 140°F (0-60°C)
COMMUNICATION
- Bluetooth: Bluetooth receiver
- CAN: CAN port for testing battery
105AH 72 Volt Professional Kit “POWER” P/N BE10572P Pro-K
Professional Kit includes everything in the Standard Kit plus installation hardware:
- 73.6V-105AH battery
- Bluetooth receiver
- Smart SOC “state of charge” meter
- Owner’s manual with simple installation instructions
- 6 – 3/8″ battery ring terminal connectors
- 10 – 10″ tie straps
- Waterproof high-speed charger
- Mounting bracket, nuts & bolts
- AC hardwire port
- DECO cover plate (universal or Club Car)
- 15 ft 12-AWG lighted extension cord
- Bolt Energy USA stickers
- 12-year transferable warranty
- 50-amp voltage reducer
- 2 – 40″ 2AWG premium installation cables
- 72V 400A heavy-duty solenoid
- Lead battery removal strap
MECHANICAL SPECIFICATIONS
- Dimensions (L x W x H): 20.08″ x 10.75″ x 10.39″
- Weight: 137.26lbs (62.26kg)
- Terminal Type: M8*1.5*25mm
- Cell Configuration: 1P23S
- Case Material: Powder Coated Steel
- Enclosure Protection: Designed with IP66 Standard
- Cell Type – Chemistry: Prismatic- LiFePO4
DISCHARGE SPECIFICATIONS
- Maximum Continuous Discharge Current: 250A
- Peak Discharge Current: 520A ± 15.6A (30S
-
BMS Discharge Current Cut-Off:
260 A ± A7.8A (50S)
520A ± 15.6A (30S) - BMS Discharge Voltage Cut-Off: 57.5V
- Recommended Low Voltage Disconnect: 69.0V
- BMS Reconnect Voltage: 60.0V
- Discharge Temperature: -4 to 149°F (-20 to 65°C)
ELECTRICAL SPECIFICATION
- Nominal Voltage: 73.6V
- Working Voltage: 62 – 83.95V
- Recommended Voltage: 69V – 81.93V
- Nominal Capacity: 105Ah
- Energy: 7,728Wh
- Capacity @ 25A: 420 min
- Efficiency: 0.99
- Self Discharge: <3% per Month
CHARGE SPECIFICATIONS
- Recommended Charge Current: 5 – 52A
- Maximum Input Current: 350A
- Charge Current Cut-Off: 375A
- BMS Charge Voltage Cut-Off: 84V
- Reconnect Voltage: <84V
- Charging Temp. Range: 34°F to 140°F (0-60°C)
COMMUNICATION
- Bluetooth: Bluetooth receiver
- CAN: CAN port for testing battery
